ODOT IP-IA-8DIP8DOP 8 DI PNP 8 DO PNP Module IP67 IO-Link Slave Module

ODOT IP-IA-8DIP8DOP 8 DI PNP 8 DO PNP Module IP67 IO-Link Slave Module

£90.00

Add to quote

Key Features

  • Supports IO-Link V1.1.4 standard, 8 Class A ports
  • Transfer Rate: Default – COM2 (38.4kbps)
  • 8 Ports; 8 channels digital input & 8 channels digital output (M12, A-code, 5 Pin, hole end)
  • IP67 protection level
  • Power supply undervoltage/overvoltage detection
  • Built-in temperature sensor & real-time monitoring
  •  Supports automatic device identification & parameter configuration
  • Dimension: 160 mm*60 mm*35.5 mm
  • Operating Temperature: -30 ℃~60 ℃
CE UKCA FCC RoHS WEEE

Description

The ODOT IP-IA-8DIP8DOP is a compact and reliable IO-Link slave module designed for industrial digital signal acquisition and output control applications. Featuring 8 PNP digital input channels and 8 PNP digital output channels, the module provides efficient bidirectional signal communication for modern industrial automation systems.

The ODOT IP-IA-8DIP8DOP is designed and proven in harsh industrial environments and integrate easily into modern automation networks. It has strong environmental adaptability, IP67 protection level, and metal casing, which can operate stably in harsh industrial environments such as moisture, dust, and oil stains. The module adopts a standard M12 connectors and have diagnostic functions including power and communication diagnosis.

ip-series-high-protection-remote-io-user-manual-v1-00-20260424
